Product features

• ? Meet 1.2/50 μ s、10/700 μ S waveform test;

• ? Ensure normal communication at various rates and no packet loss;

• ? First line, second line, four line and eight line communication can be tested.

Product parameters

• Product model:


  Coupling waveform


  Coupling voltage


  Surge polarity


  Output impedance


  Coupling / decoupling network


  transmission speed


  Coupling device


  Coupling operating voltage


  Coupling working current

• CDN-I/OE


  Voltage wave: 1.2/50 us, 10/700 us; Current wave: 8/20 us, 5/320 us


  0.2~7kV


  Positive / negative, alternating positive and negative


  1.2/50(40Q,80Q,160Q,320Q2),10/700(25Q,50Q2,100Q,200Q2)


  First line, second line, fourth line, eighth line


  1.0Gbps 、100Mbps、10Mbps 、100Kbps


  GDT (90V) can be customized in other ways


  DCo ~8ov


  Max. 2A

Product recommendation

Three Phase 10A Voltage Dips Generator

Model：VDT T10

Voltage dips/sags, short interruptions are caused by failures of the power grid and power facilities or sudden large changes in loads. In some cases, there will be two or more consecutive dips or interruptions. Voltage changes are caused by continuous changes in the loads connected to the grid. If the EUT cannot respond in time to changes in the power supply voltage, it may cause malfunctions. Voltage dips generators are used to evaluate the performance of electrical and electronic equipment when subjected to voltage dips/sags, short interruptions, and voltage changes. Products fully meet the requirements of standards IEC/EN 61000-4-11 and GB/T17626.11.

Learn more

Three phase 10kV lightning surge generator sur T10

Model：SUR T10

The impact of lightning (indirect lightning) in nature and voltage changes caused by large switch switching in power supply lines on power supply lines and communication lines is particularly large, and the impact on products may be destructive. The lightning surge generator is used to evaluate the performance of the equipment when it is subjected to high-energy disturbance from the power line port and other signal line ports. The product meets the requirements of new standards such as iec61000-4-5 and gb/t17626.5.

Learn more

Three phase 10kV multifunctional lightning surge generator sur t10l

Model：SUR T10L

The lightning surge generator sur t10l meets two kinds of surge waveforms: 1.2/50us and 10/700us. It is a surge (shock) immunity test product designed for the power port and communication port of various electronic and electrical products, which is used to evaluate the performance of electronic, electrical, communication and other products when they are subjected to high-energy disturbance from the power port and other signal ports. The product meets the requirements of new standards such as IEC 61000-4-5 and gb/t 17626.5.

Learn more
